| Printing | |
|---|---|
| Print Type | Dye-Sublimation |
| Print Area | Edge to Edge |
| Resolution | 300 dpi |
| Dual Side Printing | Option |
| Card | |
| Card Feeding | Automatic |
| Card Size | ISO Card Size CR80 (54mm x 86mm / 2.12" x 3.38") |
| Card Thickness | 0.38mm (15mil) 1.0mm (40mil) |
| Card Type | PVC, Composite PVC, PET |
| Print Speed | |
| Monochrome | 5 sec./card (720 cards/hour) |
| YMCKO | 20 sec./card (180 cards/hour) Max. 16 sec./card (220 cards/hour) |
| Capacity | |
| Input Hopper | 500 cards |
| Output Hopper | 100 cards (Standard) , 500 cards (Option) |
| Ribbon Capacity | |
| Monochrome | 2,500 cards / roll |
| YMCKO | 500 cards / roll |
| System | |
| Memory | 64MB RAM |
| Control Panel | 2 Lines LCD / 2 LED Buttons |
| Supported Platforms | Microsoft Windows 2000 /2003 /XP / Vista / 7 / 8 Mac OS, Linux |
| Communication | USB, Ethernet |
| Power Supply | Free Voltage (AC 110/220V, 50-60Hz) |
| Power Consumption | TBD |
| Temperature / Humidity | 15-35°C / 20-80% |
| Dimensions | |
| Dimensions (W x L x H) | Max. 205mm X 675mm X 535mm |
| Weight | TBD |
| Encoding Options | |
| Magnetic | ISO 7811 (Track I, II, Ill Read / Write) , HiCo/LoCo, JIS II 0 |
| Contact | ISO 7816 (ID -1) |
| Contactless (Internal & External) | MIFARE, ISO 14443 (Type A / B) , ISO 15693, DESFIRE, iCLASS |
| Certifications | TBD |
