Single or dual-sided printing. Field upgradable by installation of flipper on SMART-30D.
| Printing | |
|---|---|
| Print Mode | Dual Sided |
| Print Type | Direct Dye-Sublimation |
| Print Area | Edge to Edge |
| Resolution | 300dpi (Color & Mono), 600 & 1200dpi (Mono only) |
| Card | |
| Card Feeding | Automatic |
| Card Size | ISO CR80 (54mm x 86mm / 2.12" x 3.38") |
| Card Thickness | 0.38mm (15mil) ∼ 0.76mm (30mil) |
| Card Type | PVC, Composite PVC, PET |
| Print Speed | |
| Monochrome | 5 sec./card (720 cards/hour) |
| YMCKO | Max. 20 sec./card (180 cards/hour) |
| YMCKOK | Max. 26 sec./card (138 cards/hour) |
| Capacity | |
| Input Hooper | 80 Cards |
| Output Hooper | 25 Cards |
| System | |
| Memory | 64MB RAM |
| Control Panel | 1 LED Button |
| Supported Platforms | Microsoft Windows 2000/2003/XP/Vista/7, Mac OS, Linux |
| Communication | USB, Ethernet (Option) |
| Power Supply | Free Voltage (AC 110/220V, 50 ∼ 60Hz) |
| Power Consumption (Max) | 48W |
| Temperature / Humidity | 15 ∼ 35 C / 35 ∼ 70% |
| Dimensions | |
| Dimension (W x L x H) | 172 mm x 472mm x 190mm |
| Inch | 6.8 (W) x 18.6 (L) x 7.5 (H) |
| Weight | 4.2 kg / 9.5 lbs |
| Encoding Options | |
| Magnetic | ISO 7811 (Track I, II, III Read/ Write, HiCo/ LoCo), JIS II |
| Contact Smartcard | ISO 7816 A/B/C Card, ISO 7816 1/2/3/4 Microprocessor Card |
| Contactless Smartcard | ISO 14443 (Type A/ B), MIFARE, DESFIRE, iCLASS, ISO 18092(NFC), Felica, |
| Certifications | CB, CE, FCC, KC, CCC |
